Specifications

parameter

switching capacity

128Gbps

Packet forwarding rate

132Mpps

MAC table entry

8K

Buffer value

4M

Jitter delay

9.62ns

Size

440mm × 265mm × 45mm

weight

5kg

Power

450W

working temperature

0~55°C

Storage temperature

-10~70°C

Working humidity

10%~90% no condensation

Storage humidity

5%~95% no condensation

VLAN

Maximum support for 4096 VLANs

Support port-based VLAN

VLAN Supporting 802.1Q Standard

spanning tree

Support RSTP Fast Spanning Tree Protocol

Ring network

Supporting Fast Loop Networks

Erps

support

Route

Static Route, OSPF

Port aggregation

Support static aggregation

Port mirroring

Support multi-to-one port mirroring without restriction on the number of mirror source ports

Loop Guard

Supporting Loop Detection/Loop Avoidance

Port flow control

Supporting half-duplex control based on backpressure

line rate

Support port-based input/output bandwidth management

IGMP Snooping

Support IGMP Snooping

DHCP

Support DHCP Client

Storm suppression

Supporting suppression of broadcasting, multicast, unicast, etc

Negotiation mode

Support port auto-negotiation (self-negotiation transmission rate and duplex mode)

system maintenance

Supporting profile upload/download

Support upgrade package upload

Support WEB to restore factory configuration

Support System Logging Function

Network management

Support WEB interface management, CONSOLE,Telnet
